    8000rpm Small Double Column Machining Center Gantry Type Precision CNC Machining

    Ask Lasest Price
    Brand Name : JOINT
    Model Number : BTMC-1220
    Certification : ISO 9001:2015
    Price : NEGOTIATION
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 1000 SETS/YEAR
    Delivery Time : NEGOTIATION
    • Product Details
    • Company Profile

    8000rpm Small Double Column Machining Center Gantry Type Precision CNC Machining

    8000rpm Small Double Column Gantry Type Machining Center CNC


    BTM 10/12 series is the upgrade product of big size VMC machine (1270/1370/1580/1690/1890) advantages.


    ◆High precision key parts: Linear way, ball screw from Germany or Taiwan top brand products, Japan


    NSK/P4 class tight bearing.


    ◆Adopted Taiwan BT50 rotary machinery spindle, two axis linear way, suitable for large mold and parts high


    speed processing.


    ◆High rigidity gantry fixed beam structure, to ensure the stability of the machine body under strong cutting


    and high speed cutting conditions.


    ◆Adopted temperature compensation technology, to improve the processing accuracy under long - time


    processing conditions.


    8000rpm Small Double Column Machining Center Gantry Type Precision CNC Machining

    8000rpm Small Double Column Machining Center Gantry Type Precision CNC Machining

    ModelBTMC-1220
    Table size1000*2200mm
    X/Y/Z travel2000*1200*700mm
    Distance between tool head and table500-850mm
    Work table Y slot (NO.-size*pitch)7-22*125mm
    Width of gantry1270mm
    Spindle rotation speed6000 rpm/min (optional 8000rpm/min)
    Spindle TaperBT50(φ155/190mm)
    Spindle Motor15kw
    X/Y/Z axis Rapid feed12/12/8 m/min
    Positioning accuracy0.01mm
    X/Y/Z axis Cutting feed8 m/min
    Dimension7260*3210*3920mm
    Net weight14000kg
    Max load of table3500kg
