    Large Load Carrying Capacity CNC VMC Machine BT40 8000rpm Spindle VMC1270L3

    Ask Lasest Price
    Brand Name : JOINT
    Model Number : VMC1270L3
    Certification : ISO 9001:2015
    Price : NEGOTIATION
    Payment Terms : TT/LC/DA/DP
    Supply Ability : 1000 SETS/YEAR
    Delivery Time : NEGOTIATION
    • Product Details
    • Company Profile

    Large Load Carrying Capacity CNC VMC Machine BT40 8000rpm Spindle VMC1270L3

    3 axis Linear Guide Way Vertical machine center VMC1270L3 BT40 8000rpm Spindle


    Product features:


    1.The spindle unit of the machine tool is high speed, high accuracy, high rigidity, with large load carrying capacity of axial and radial, and the maximum speed of up to 8000rpm.

    2.Spindle is of central blowing structure. When the spindle releases tool , the high pressure gas is used to clean the main shaft, so ensure the precision and service life of the tool.

    3.Guide rail and ball screw of X, Y, Z direction are all use protection device to ensure that the screw and the guide is clean and the accuracy and life of machine tool's transmission and movement.

    4.The machine tool external protection of machine tool uses the full protection structure. It is convenient operation, safe and reliable, and nice shape.

    5.It uses a reliable device which is automatic and centralized to lubricate. It can lubricate automatically and intermittently to all lubrication points of CNC Machine. And it can settle lubricating time according to operating conditions.


    FAQ:


    Q: Are you trading company or manufacturer ?
    A: We are factory.


    Q: How long is your delivery time?
    A: Normally 10 days if the goods are in stock or 30-45 days if the goods are not in stock.


    Q: What is your terms of payment?
    A: 30% T/T in advance, balance before shipment or irrevocable 100% L/C at sight.


    Specification Of Vertical machine center VMC1270L3


    ModelUnitVMC-1270L3
    TravelX axismm1200
    Y axismm700
    Z axismm650
    Distance between spindle and tablemm230-880
    Working tableTable sizemm1360*700
    Max. Load of tableKg1000
    T slotPcs-mm-mm5-18-122
    Positioning accuracyX/Y/Z axismm0.008/0.008/0.008
    Repeated positioning accuracyX/Y/Z axismm0.006/0.006/0.006
    SpindleSpindle rotation speedRpm8000
    Spindle taperBT40
    DiametermmΦ150
    Rivet modelBT40 45°
    Rapid feedX/Y/Z axism/min24/24/24
    Cutting feedX/Y/Z axism/min10
    Tool magazineUmbrella typeSizeTools20
    Too changing time (T-T)Sec6
    Max. diameter/ length/weight of toolmm100/200/8
    Max tool diameter (no tool adjacent)mm180
    Arm typeSizeTools24
    Tool changing time (T-T)sec2.5s
    Max. diameter/ /length/weight of toolmm80/200/8
    Max tool diameter (no tool adjacent)mm150
    Total capacity of electricKVA35
    Weight of machine

    Kg


    9100
    Dimensionmm3560*3300*3250

    Standard Accessories:


    Fanuc/Mitsubishi Controller system


    Full enclosed cover


    Spindle encoder position system


    Three axis inner encoder feedback system


    Auto lubrication system


    Pneumatic system


    RS 232 Interface


    Operation unit


    Working light


    Tool and tool box


    Optional accessories:


    Siemens controller or other controller system


    Spindle oil coolant


    Umbrella type tool magazine


    Arm type tool magazine


    Screw type auto conveyor


    Chain type tool magazine


    4 Axis rotary table


    Ring spray spindle
