    3.7kw 20000rpm CNC Drilling And Tapping Machine ATC Vertical

    Ask Lasest Price
    Brand Name : GIONT
    Model Number : VTC-500C
    Certification : ISO9001
    Price : Negotiation
    Payment Terms : L/C, D/A
    Supply Ability : 35sets
    Delivery Time : 30-35 working day
    • Product Details
    • Company Profile

    3.7kw 20000rpm CNC Drilling And Tapping Machine ATC Vertical

    Quality reliability and processing performance are more prominent

    This series of products are manufactured according to imported machine quality standards, with high stability, high speed and high efficiency drilling processing. It is widely used in 3C industry, electronic shell processing, aerospace, automotive small parts, medical equipment and other industries to process parts, shells, etc.


    Specification


    ModelVTC-500C
    Table sizemm650*400
    X axis travelmm500
    Y axis travelmm400
    Z axis travelmm300
    Distance between spindle and tablemm150~450
    Distance between spindle and columnmm464
    Spindle rotation speedrpm20000
    Spindle taperBT30/ Φ100 short nose spindle
    Spindle motorkw3.7
    T slot sizemm3-14*125
    Three axisLinear guide way
    ATC type16 tool ATC
    Max length/ weight of toolmm/kg200/3
    X aixs rapid feedm/min48
    Y aixs rapid feedm/min48
    Z aixs rapid feedm/min48
    Cutting feedm/min12
    Positioning accuracymm/m0.005
    Min. set moving unitmm0.001
    Dimension (L*W*H)mm1680*1600*1930
    Weightkg2800
    Max. load of tablekg250



    Standard accessories

    1. Mitsubishi/ Fanuc controller system
    2. Fully enclosed cover
    3. ATC
    4.
    Pneumatic system
    5. Auto lubrication system

    6. Work piece coolant system
    7. Air gun+Water gun

    8. Operation unit
    9. RS232 Interface
    10. Alarming light
    11. Working light
    12. Guide way cover
    13. Tools and toolbox
    14. Technical documents
    15. Spindle oil coolant
    16. Heat exchange


    Application Industry
