    10*50inch 3HP R8 Spindle Manual Vertical Turret Milling Machine

    Ask Lasest Price
    Brand Name : JOINT
    Model Number : 3E
    Certification : ISO 9001:2015
    Price : Usd2600.00-Usd6000.00/set
    Payment Terms : TT/LC/DA/DP
    Supply Ability : 1000 SETS/YEAR
    Delivery Time : 10-30 work day
    • Product Details
    • Company Profile

    10*50inch 3HP R8 Spindle Manual Vertical Turret Milling Machine


    10*50inch Travel 3HP R8 Spindle Manual Vertical Turret Milling Machine


    10*50inch 3HP R8 Spindle Manual Vertical Turret Milling Machine

    Feature


    3E Spindle tolerance is 0.005mm.

    Its milling head adopts 3HP motor, 16 steps speed pulley head, variable speed head is optional.

    This type of model is taiwan parts assembled in China.

    The treble swallowtail guide way is adopted on three axis, so it is easy to adjust and repair.

    It is suitable for household appliances, daily necessities mold processing.

    10*50inch 3HP R8 Spindle Manual Vertical Turret Milling Machine


    Specification

    Model3E
    Table size1270*254*90mm
    X axis travel880mm
    Y axis travel395mm
    Z axis travel360mm
    Travel of spindle quill127mm
    Max distance from the spindle nose to table400mm
    Spindle rotation speed80-5440/(16Grades)/60HZ 66-4530/(16 Grades)/50HZ
    Spindle TaperNT30/R8
    Spindle Rated power3HP
    Tilt angle Forward and backward±45°(±0° optional)
    Tilt angel left and right±90°
    Dimension1500*1700*2150mm
    Net weight

    1200kgs


    Machine Picture

    10*50inch 3HP R8 Spindle Manual Vertical Turret Milling Machine


    10*50inch 3HP R8 Spindle Manual Vertical Turret Milling Machine


    Standare Accessories


    Way cover , Tool and tool box ,draw bar ,manual pump ,Working light

    10*50inch 3HP R8 Spindle Manual Vertical Turret Milling Machine

    10*50inch 3HP R8 Spindle Manual Vertical Turret Milling Machine


    Optional Accessories


    Three axis DRO , Two axis DRO, Clamping kit , NT30/NT40 Milling chuck , X axis power feed ,Coolant system


    6 Vise ,8 Vise , Power bar , Z axis Elevator motor


    10*50inch 3HP R8 Spindle Manual Vertical Turret Milling Machine


    Optional For Milling Head


    10*50inch 3HP R8 Spindle Manual Vertical Turret Milling Machine

    Square type step Speed Variable Speed Milling head Inverter Speed Milling Head Step Speed Milling Head

    Milling head

    10*50inch 3HP R8 Spindle Manual Vertical Turret Milling Machine


    Why Choice JOINT machine ?


    A:Chinese TOP 10 Brand of milling machine


    B: 26 Years professional Machinery manufacturer


    C. China HI-TECH Enterprise


    D.SHENZHEN TOP Brand
