3600rpm Turret Head Milling Machine 5HP Boring With Drawbar

    Buy cheap 3600rpm Turret Head Milling Machine 5HP Boring With Drawbar from wholesalers

    Buy cheap 3600rpm Turret Head Milling Machine 5HP Boring With Drawbar from wholesalers
    • Buy cheap 3600rpm Turret Head Milling Machine 5HP Boring With Drawbar from wholesalers

    3600rpm Turret Head Milling Machine 5HP Boring With Drawbar

    Ask Lasest Price
    Brand Name : JOINT
    Model Number : 6VA
    Certification : ISO 9001:2015
    Price : NEGOTIATION
    Payment Terms : L/C, T/T
    Supply Ability : 1000 SETS/YEAR
    Delivery Time : NEGOTIATION
    • Product Details
    • Company Profile

    3600rpm Turret Head Milling Machine 5HP Boring With Drawbar

    Key Advantages:

    1. This series of milling machine is suitable for precision electronic machinery, precision electronic components, mold accessories and other precision parts of the hole, slot, frame.

    2. Second time precison scraping assembly process, to ensure the precision grade of the machine

    3. High quality Taiwan original milling head, Japan NSK P4 level preicision spindle bearing. Spindle runout: 0.003mm.

    4. 300 spindle detection rod section runout is 0.02mm.


    Specification:

    Model6VA
    Table sizemm1370*330*99
    TravelX axismm850
    Y axismm390
    Z axismm450
    Travel of spindle quillmm150
    Maximum distance from spindle nose to tablemm570
    SpindleRotation speed
    (Step speed milling head)
    50HZrpm60-3000
    60HZrpm70-3600
    Rotation speed
    (Variable speed milling head)
    50HZrpm60-3250
    60HZrpm70-3900
    Rotation speed
    (Inverter speed milling head)
    50HZrpm0-4200
    60HZrpm0-4200
    TaperNT40
    Rated powerHP5HP
    Tilt angleForward and Backward±45°
    Left and Right±90°
    Dimensionmm1600*2000*2450
    Net weightkg2000

    VA series standard accessorie:


    1. Taiwan original step milling head

    2. Working light

    3. Guideway cover

    4. M12 clamping kit

    5. R8 collet (7 pcs)

    6. Drawbar

    7. Manual oil pump

    8. Accompanied toolbox


    Optional accessories:


    1. 6'' or 8'' vise

    2. Electric power feed (2 axis and 3 axis)

    3. Mechnical power feed (2 axis and 3 axis)

    4. Water pump+water tray

    5. Dro(2 axis or 3 axis)




    Overview:




    Package:
